INTELLIGENT FIRE ALARM PANEL

OBMP00020

Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book. It has survived not only five centuries, but also the leap into electronic typesetting, remaining essentially unchanged. It was popularised in the 1960s with the release of Letraset sheets containing Lorem Ipsum passages, and more recently with desktop publishing software like Aldus PageMaker including versions of Lorem Ipsum.

Technical Details

Feature
? Two loop addressable fire detection panel packed with features not usually associated with smaller systems, providing a high quality solution at exceptionally good value
? Loop capacity 477 intelligent devices
? 30 logical configurable zones
? PAS and Acknowledge Function
? Duplicate address report
? Mismatch device type report
? Dirty Detector Reporting
? One Man Test Function
? Graphical LCD Display
? Zone indication and manual intervention panel
? Net-workable with all GST intelligent fire panels
? Programmable from PC
? Built-in RS485 repeater output (Maximum 10 repeaters)
? Optional GMC graphic station
? Optional Panel Printer
? Advanced user friendly programming software including ‘Fuzzy Logic’
? Optional protection of re-programming
? Approved by LPCB
Technical Specifications
? Standard: EN54 Part 2/4 ? Approvals: LPCB, CE
? Main Input Voltage: 220/230 VAC (+10/-15%) 50/60 Hz
? Input Current Rating: 0.5A
? System Operating Voltage: 24 VDC Nominal
? Loop Capacity: Loop 1: 235; Loop 2: 242
? Outputs (3):
      Fire Alarm Output: 500mA /24Vdc/NO-NC
       F.P.E. Output: 500mA /24Vdc/NO-NC
       Sounder Circuit Output: 500mA /24Vdc/NO-NC
? Dimension: (HWD) 580 x 420 x 202 mm
