PENX

OBMP00032

Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book. It has survived not only five centuries, but also the leap into electronic typesetting, remaining essentially unchanged. It was popularised in the 1960s with the release of Letraset sheets containing Lorem Ipsum passages, and more recently with desktop publishing software like Aldus PageMaker including versions of Lorem Ipsum.

Technical Details

System CapacityETERNITY PENX
Universal slots6
FXS Ports (SLT)48
DKP Port16
IP User100
FXO Ports (CO)16
PRI ports2
GSM/3G/LTE Ports8
SIP Trunks50
Max. VoIP Channel64
Max. VMS Channel16
Max. IP to IP Call (Transcoding)32
Max. IP to IP Call (DRTP/Relay RTP)64
Max. IP to TDM Call64
Max. TDM to TDMNon-Blocking
No of Voice Module16
Simultaneous Voice Module Playback5
Max. Audio conference Participants (System Wide)48
Max. Audio conference Participants (In a single Multi-Party Conference)15
Max. Number of Simultaneous 3-party conference16
VoIP ProtocolSIP, SDP, RTP, SRTP
Network ProtocolIPV6, IPV4, TCP, UDP, VLAN, DHCP, PPPoE, QoS, STUN
Transport ProtocolUDP, TCP, TLS
CodecG.711(A-law, ?-law), G.723,G.729AB,GSM-FR,iLBC
DTMFRTP(RFC2833), SIP Info, IN-Band
LANGigabit port
WANGigabit port
VoicemailYes
Call Recording2170 Hr.
Max. External Storage32GB
Inter USB Port1
External USB Port1
EnvironmentOperation Range: 0°C to 45°C,
Storage Range: -20°C to +70°C,
Operating Humidity: 5-95% RH Non-Condensing
Mounting1U Rack Mount
