NENXIP50
Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book. It has survived not only five centuries, but also the leap into electronic typesetting, remaining essentially unchanged. It was popularised in the 1960s with the release of Letraset sheets containing Lorem Ipsum passages, and more recently with desktop publishing software like Aldus PageMaker including versions of Lorem Ipsum.
Technical Details
| Particulars | NENX416 |
|---|---|
| FXO Ports (CO) | 4 |
| FXS Ports (SLT) | 16 |
| GSM/3G Ports | 2 |
| IP Users | 50 |
| VoIP Trunks (SIP) | 8 |
| Max. VoIP CHNL | 8 |
| Max. VMS CHNL | 4 |
| Max. IP to IP Call | 25 |
| Max. IP to TDM Call | 8 |
| Conference | 6 party |
| Video Calls | 8 |
| VoIP Protocol | SIP, SDP, RTP, SRTP |
| Network Protocol | IPv6, IPv4, TCP, UDP, DHCP, VLAN, DynDNS, PPPoE, QoS, STUN |
| Transport Protocol | UDP, TCP, TLS |
| Codec | G.711(A-law, ?-law), G.723, G.729AB, GSM-FR, iLBC |
| DTMF | RTP (RFC2833), SIP Info, IN-Band |
| LAN | 1 × 10/100 Mbps |
| Voicemail | Yes |
| T.38 Fax | Yes |
| Max. External Storage | 32GB |
| USB | 1 (With Factory fitted 8 GB Pen-drive) |
| Power | 24VDC 2.5Amp |
| Size | 320.2 x 51.1 x 208.1 mm |
| Power Consumption | 15W |
| Environment | Operation Range: 0°C to 45°C, Storage Range: -20°C to 65°C, Operating Humidity: 5-95% RH Non-Condensing |
| Mounting | 1U Rack Mounting |
