NEC SL2100

OBMP00042

Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book. It has survived not only five centuries, but also the leap into electronic typesetting, remaining essentially unchanged. It was popularised in the 1960s with the release of Letraset sheets containing Lorem Ipsum passages, and more recently with desktop publishing software like Aldus PageMaker including versions of Lorem Ipsum.

Technical Details

Number of Chassis1 Chassis2 Chassis3 Chassis
Number of Universal Slot4812
Number of CPU1
Total System Ports (Trunk + Extension)222
Total Legacy Ports (Trunk + Extension)74148222
Trunks (Max.)4284126
- Analog122436
- ISDN BRI1632636
- ISDN PRI (2M)306090
Extensions (Max.)74112112
- Multi-line Terminals244872
- Analog Extensions326496
- DSS Console369
- Doorphone6
IPIP Trunks (SIP / H.323)64
 IP Extensions112
Audio / OthersRelay11
 Paging3
 External Music on Hold1
 BGM1
 Ethernet Port1
 Analog Modem1
Voice Response
System/ Voice Mail
(VRS/VM)		VRS/VM Storage2 Hours (Built-in) / 15 Hours (By Small SD card) /
120 Hours (By Large SD card)
 Voice Prompts for VRS/VM1 Language (Built-in) / 26 Languages
(By Small or Large SD card)
VoIPBuilt-In VoIP Channel8 (Built-in) / 128 (By VoIP board)
Physical CharacteristicsSL2100 Chassis DimensionsH 92.9mm X W 435mm X  D 330mm
 Empty Chassis Weight2.2 Kg
Power ConsumptionSL2100 Chassis Power RatingInput 100V-120V/220V/230V/240V
50/60Hz 1.43A 1.25A/0.82A/0.79A/0.76A
OR DC-24V 2.86A
ComplianceEMCEN55032 Emission, EN55024 Immunity,
EN6100 Powering
 SafetyEN60950-1
 Transmission and SignalingTBR3, TBR4, ES203-021, TBR8, TBR38
EnvironmentTemperature0°C~40°C (32F-104F)
 Humidity10%~90% (non-condensing)
