AUDIO CONFERENCING SYSTEM
Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book. It has survived not only five centuries, but also the leap into electronic typesetting, remaining essentially unchanged. It was popularised in the 1960s with the release of Letraset sheets containing Lorem Ipsum passages, and more recently with desktop publishing software like Aldus PageMaker including versions of Lorem Ipsum.
Technical Details
| User interface features |
|---|
| • Gesture-based, multitouch-capable capacitive touch screen |
| • 5-inch color LCD (720 x 1280 pixel), 9:16 aspect ratio |
| • On-screen virtual keyboard |
| • 1 USB 2.0 Type A-compliant port USB battery charging BC1.2 compliant (requires full Class 4 power input on LAN IN for operation) |
| • Integrated Bluetooth 4.0 and NFC |
| • 3 multicolored capacitive-touch mute indicators |
| • Unicode UTF-8-character support |
| • User interface localized in Arabic, Chinese, Danish, Dutch, English (Canada/ US/UK), French, German, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Slovenian, Spanish and Swedish |
| Audio Features |
| • 3 cardioid microphones |
| • Loudspeaker - Frequency: 100-22,000 Hz - Volume: 92 dB at 0.5m peak volume |
| • 6m/20-foot microphone pickup range |
| • Supported codecs: - G.711 (A-law and ?-law) |
| • Polycom® Siren™ 7 (16kbps) |
| • Polycom® Acoustic Clarity™ technology provides full-duplex conversations, acoustic echo cancellation and background noise suppression - Type 1 compliant (IEEE 1329 full duplex) |
| • Polycom® NoiseBlock™ |
| • Voice activity detection |
| • Comfort noise generation |
| • DTMF tone generation (RFC 2833 and in-band) |
| • Low-delay audio packet transmission |
| • Adaptive jitter buffers |
| • Packet loss concealment |
| • Bluetooth device pairing for wideband speech and multimedia streaming (HFP/AD2P) |
| • Call handling features |
| • 1 line (registration) |
| • Shared call/bridged line appearance |
| • Distinctive incoming call treatment/call waiting |
| • Call timer and call waiting |
| • Call transfer, hold, divert (forward), pickup |
| • Called, calling, connected-party information |
| • One-touch speed dial |
| • Do-not-disturb function |
| • Local configurable digit map/dial plan |
| • Corporate directory access using LDAP |
| • Visual conference management |
| Power |
| • LAN IN: Built-in auto-sensing IEEE 802.3at. PoE Device (Class 4) (requires full Class 4 power input on LAN IN for operation). Backward compatibility with IEEE 802.3af. |
| • LAN OUT: Built-in auto-sensing IEEE 802.3af power sourcing equipment (requires full Class 4 power input on LAN IN for operation) |
| Environmental conditions |
| • Operating temperature: 0 to 40°C (+32 to 104°F) |
| • Relative humidity: 5% to 95% (non-condensing) |
| • Storage temperature: -20 to +70°C (-4 to +160°F) |
| Phone dimensions (L x W x H) |
| • 38.3 x 7.5 x 33.2 cm (15.1 x 2.9 x 13.1 in) |
| • Unit weight: 0.95Kg (2.1 lbs) |
| Box dimensions (L x W x H) |
| • 48.3 x 11.5 x 39.4 cm (19 x 4.5 x 15.5 in) |
| • Box weight: 1.97 Kg (4.35 lbs) |
