BOARD ROOM SOLUTIONS 2
Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book. It has survived not only five centuries, but also the leap into electronic typesetting, remaining essentially unchanged. It was popularised in the 1960s with the release of Letraset sheets containing Lorem Ipsum passages, and more recently with desktop publishing software like Aldus PageMaker including versions of Lorem Ipsum.
Technical Details
| Board Room Solution | ||
|---|---|---|
| Audio – Digital | ||
| Streaming Formats | AAC, aacPlus, Apple Lossless (ALAC), HE-AAC, LPCM, MP3, WAV, WMA, WMA Lossless, WMA-PRO | |
| Output Resolution/Bitrate | Up to 24-bit 48 kHz | |
| Audio – Analog | ||
| D-A Conversion | Up to 24-bit 48 kHz | |
| Frequency Response | 20 Hz to 20 kHz, ±1 dB | |
| S/N Ratio | >110 dB | |
| THD+N | < -100 dB | |
| Communications | ||
| Ethernet | 10/100 Mbps, auto-switching, auto-negotiating, auto-discovery, full/half duplex, DHCP, IEEE 802.3af and 802.3at Type 1 compliant | |
| USB | USB 2.0 host for connection of Apple® iOS® devices | |
| Connectors | ||
| AUDIO OUT, L/R | (1) pair RCA female; Unbalanced stereo line-level audio output [6]; Output Impedance: 100 Ohms; Maximum Output Level: 2 Vrms | |
| AUDIO OUT, S/PDIF | (1) RCA female; S/PDIF coaxial digital audio output [6]; Output Impedance: 75 Ohms | |
| iPod/iPhone | (1) USB Type A female; USB 2.0 host port for connection to an Apple iOS device; Provides power for charging an iPhone® or iPod® device; does not charge iPad® devices | |
| LAN/PoE | (1) 8-pin RJ45 female; 10Base-T/100Base-TX Ethernet port, Power over Ethernet compliant | |
| G | (1) 4-40 screw, chassis ground lug | |
| Controls & Indicators | ||
| PWR | (1) Dual-color green/amber LED, indicates operating power supplied via PoE, lights amber while booting and green when operating | |
| NET | (1) Amber LED, indicates Ethernet link status | |
| RESET | (1) Recessed pushbutton for hardware reset | |
| SETUP | (1) Red LED and (1) recessed pushbutton, for Ethernet setup | |
| ACTIVE STREAM | (1) Amber LED, indicates the CEN-NSP-1 is actively streaming audio from an iOS device or Internet radio | |
| LAN/PoE | (2) LEDs, green indicates Ethernet link status, amber indicates Ethernet activity | |
| Power Requirements | ||
| Power over Ethernet | IEEE 802.3at Type 1 (802.3af compatible) Class 0 (12.95 W) PoE Powered Device; Requires a PoE injector or PoE switch [4] | |
| Environmental | ||
| Temperature | 41° to 113° F (5° to 45 ° C) | |
| Humidity | 10% to 90% RH (non-condensing) | |
| Heat Dissipation | 17 BTU/hr | |
| Construction | ||
| Enclosure | IFE small form factor, black and blue plastic | |
| Mounting | Freestanding, stackable, surface mount, or 35 mm DIN EN 60715 rail mount; occupies 8 DIN module spaces (144 mm); surface/DIN rail mounting bracket included, optional rack mount and pole mount kits sold separately | |
| Dimensions | ||
| Height | 1.35 in (35 mm); 1.77 in (45 mm) with bracket | |
| 5.04 in (128 mm); 5.36 in (137 mm) with bracket | ||
| Depth | 5.10 in (130 mm) | |
| Weight | ||
| 11.2 oz (318 g) | ||
