CARD BASED CONTROLLER
Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book. It has survived not only five centuries, but also the leap into electronic typesetting, remaining essentially unchanged. It was popularised in the 1960s with the release of Letraset sheets containing Lorem Ipsum passages, and more recently with desktop publishing software like Aldus PageMaker including versions of Lorem Ipsum.
Technical Details
| Credential Support | BLE, Fingerprint and RFID Card |
| Template Per User | Up to Ten (Single Template per Finger Mode) or Up to Five (Dual Template per Finger Mode) |
| Card Type | EM Prox (COSEC PATH DCFE) MIFARE Classic® Smart (COSEC PATH DCFM) HID iCLASS, HID Prox (COSEC PATH DCFI) |
| Template Storage Capacity | SFM 6030: 25,000 (1:N) And 100,000 ( 1:1) |
| Cards Per User | Two |
| Events Buffer | 5,00,000 |
| Max. Users | 50,000 |
| RS-485 | Yes (115.2Kbps) |
| Battery Backup | No |
| Ethernet | Yes (10/100Mbps) |
| PoE | Yes (IEEE 802.3 af) |
| Exit Switch | Yes |
| Door Status Sense | Yes (2 State) |
| Door Lock Relay | Form C and SPDT Relay (Max 1A@30 VDC) |
| Door Lock Power | Internal 12V DC @ 0.5 Amp |
| Reader Interface types | RS-232 and Wiegand IN/OUT |
| Buzzer | Yes |
| LED | Single LED (TriColor ) |
| CPU | Cortex A8 800 MHz |
| Flash Memory | 512 MB |
| RAM Memory | 512 MB |
| Input Power | 12V DC @ 2A |
| Humidity | 5% to 95% RH Non – Condensing |
| Operating Temperature | 0°C to +50°C (32°F to 122°F) |
| Tamper Detection | Yes |
| IP65 | Verified |
| Certification | CE and BIS |
| Dimension (mm) | 50.5X160X44 |
| Weight (kgs) | 0.27 |
| Wi-Fi | Yes (802.11 b/g/n) |
