PVR - MATRIX
Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book. It has survived not only five centuries, but also the leap into electronic typesetting, remaining essentially unchanged. It was popularised in the 1960s with the release of Letraset sheets containing Lorem Ipsum passages, and more recently with desktop publishing software like Aldus PageMaker including versions of Lorem Ipsum.
Technical Details
| Credential Support | Palm, Card and PIN |
| Display | 128 x 64 Dot Matrix Display |
| Keypad | 16 Touch Sense Keys |
| User Capacity | 10,000 |
| Template Storage Capacity | 20,000 |
| Template Per User | Up to Two Palms |
| Cards Per User | Up to Two |
| Types of Cards Support | EM Prox, HID iCLASS and Mifare (Card Module Required) |
| Event Buffer (Storage Capacity) | 1,00,000 |
| Mobile Broadband | Yes (3G/4G Support) |
| Wi-Fi | Yes (802.11 b/g/n) |
| Ethernet | Yes (10/100 Mbps on Ethernet) |
| Exit Switch | Yes |
| Door Status Sense | Programmable NO, NC and Supervised |
| Door Lock Relay | Form C, SPDT Relay (Max 2A@30 VDC) |
| Door Lock Power | Internal 12VDC @ 0.5A or External |
| Aux-IN | Programmable NO, NC and Supervised |
| Aux-OUT | Form C and SPDT Relay (Max 2A@30 VDC) |
| Reader Interface types | RS 232 sand Wiegand IN/OUT |
| Reader Types | 1 Port for Card Reader/Third Party Wiegand Reader |
| USB | 2 USB Ports (1 for Data Transfer/External Sensor Connectivity and 1 for 3G/4G Dongle) |
| LED | 4 LEDs (Status, Alarm, Allowed, Denied) |
| Buzzer | Yes |
| CPU | 1 GHz ARM Cortex A8 based Processor |
| Flash Memory | 256MB Flash |
| RAM Memory | 512 MB DDR3 RAM |
| Input Power | 12VDC @ 2A |
| Battery Backup | No |
| Reader Power Output | Internal 12VDC @ 0.5A or External |
| Humidity | 5% to 85% RH Non-condensing |
| Tamper Detection | Yes |
| Operating Temperature | 0°C to + 50°C (32°F to 122°F) |
