IP FISH EYE CAMERA
Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book. It has survived not only five centuries, but also the leap into electronic typesetting, remaining essentially unchanged. It was popularised in the 1960s with the release of Letraset sheets containing Lorem Ipsum passages, and more recently with desktop publishing software like Aldus PageMaker including versions of Lorem Ipsum.
Technical Details
| IP Fish Eye Camera Specification | ||
|---|---|---|
| Image Sensor | IMX326 | |
| Main processor | HI3516D | |
| Resolution | 4MP | |
| E?ective Pixels | 2048(H)*2048(V) @25fps | |
| Compression | H.265/H.264/JPEG/AVI | |
| TV System | PAL/NTSC | |
| Electronic Shutter Time | Auto: PAL 1/25-1/10000Sec; NTSC 1/25-1/10000Sec | |
| S/N Ratio | ?52dB | |
| Scanning System | Progressive | |
| Audio | 2-way audio(3.5mm audio interface) | |
| Alarm | 1channel Input/Ouput | |
| SD Card | support 64G Micro SD | |
| Video Output | Network/CVBS | |
| Lens | ||
| Focus Length | 1.05mm | |
| Focus Control | Fixed | |
| Lens Type | Fixed | |
| Pixels | 2MP/4MP/5MP | |
| Night Vision | ||
| Infrared LED | 42µx 3PCS | |
| Infrared Distance | 20M | |
| IR Status | Under 10 Lux By CDS | |
| IR Power On | CDS Auto Control | |
| Network | ||
| Ethernet | RJ-45 (10/100Base-T) | |
| Protocol | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, SMTP | |
| ONVIF | Support ONVIF 2.4 | |
| P2P | YES, Support QR Code | |
| POE | internal, Support IEEE 802.3af | |
| WIFI | N/A | |
| Video Delay | 0.3S (Within the Lan) | |
| Stream | ?sheye Main Stream +?sheye substream 25fps@(2048×2048), 15fps@(720×720), 15fps@(1024×768)*3 | |
| Max Resolution | 2048 × 2048 | |
| IE Brower | IE8-11, Google Chrome, Firefox, Safari, Mac Safari | |
| Smart Phone | iPhone, iPad, Android, Android Pad | |
| Camera Features | ||
| Day/Night | Color/ B&W (IR-CUT ) | |
| Image Con?g | Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, BLC, FLK(Flicker Control) | |
| Defog Mode | Support | |
| Motion Detection | Support | |
| Privacy Masking | 3 Rectangular Zone | |
| WDR | Support | |
| Recording Mode | NVR/NAS/CMS/Web | |
| Language | "Chinese Simpli?ed, Chinese Traditional, English, Bulgarian, Polish, Farsi, German, Russian, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian, Nederlands" | |
| General | ||
| Housing | Body:Metal, Bracket: Plastic | |
| IR Cut Filter | YES | |
| Operation Temperature | -20? ~ +60? RH95% Max | |
| Storage Temperature | -20? ~ +60? RH95% Max | |
| Power Source | DC12V±10%, 1000mA | |
| Dimension | ?120 x 49(H) mm | |
| Weight | 500g | |
